PCF79XX-Adapter for VVDI PROG Programmer
The VVDI Prog PCF79XX-Remote renew Adapter is used to renew smart keys & various remote control types
1. Supported Chip models:
- PCF7922 PCF7941 PCF7945 PCF7952 PCF7953 PCF7961
2. Two optional ways to read write PCF79XX chip
- Remove the chip and put it in the IC socket, select the option “PCF79XX chip” shown as follows.
- Connect the wire to the circuit board, select the option “PCF79XX adapter” shown as follows.
VVDI Pro Options Description
- “EEPROM”: data storage space, it can read & write in protected status.
- “EROM”: program memory space (equal to other chip’s FLASH space), it can read & write in unprotected status.
“Protected”: click “Protected” to lock chip and unable to read out chip data.
“Unprotected”: click “Unprotected” to unlock the chip and able to read out the chip data. After unlock, the original data in the chip will be cleared.
PCF79XX chip Function
- Currently, the PCF79XX chip support lock, unlock, and read/write data.
- RENEW function will be added in the coming days, it will load corresponding data and directly renew the key, the detailed specific car model data will be released.
If the PCF79XX adapter option can't recognize the chip due to the affection of the circuit board, just remove the chip and put it in the IC socket, then use option “PCF79XX chip” to operate.
