MS80 New Generation Motorcycle Diagnostic Scanner

Description:

This OBDSTAR MS80 has a high-level intelligent diagnosis, providing an unprecedented intelligent diagnosis and maintenance experience the first fault guidance, technical bulletin, data flow assistance, diag socket, and additional features to help you diagnose accurately and efficiently, exclusive digital circuit diagram and electrical query system, easy troubleshooting Failure, so you have no concerns about the car diagnosis.

Our New Generation Motorcycle Diagnostic Scanner features The first fault guidance, Help data, technical bulletin, diag socket, etc. to help you diagnose accurately and efficiently. Exclusive interactive circuit diagram and electrical description lookup function, so that you can have a worry-free diagnosis,

Diversified data stream display modes such as text, waveform diagram, and instrument diagram, allowing you to easily analyze faults, Automatic scanning, automatic VIN recognition, computer system programming and coding, ECU setting, instrument coding, tire pressure sensor system, service light reset, CO adjustment, idle readjustments, A/F value reset, ABS control unit setting, EOL mode, auto memory reset, erasing computer memory, etc.

Features:

• New Android 5.1.1 operating system.
• Simple and intuitive menu guidance allows you to quickly master the equipment operation.
• Provide complete diagnostic functions including code reading, code clearing, data flow, action test, setting, coding, etc.
• Menu Arbitrary selection is more convenient and quick.
• Record and playback real-time data streams, quickly and accurately locate sensor and component faults.

Specification:

• Operating System: Android 5.1.1
• CPU: Exynos4418 Dual Core ARM Cortex A9
• Battery: 3700mA, rechargeable polymer lithium battery
• Extension memory card:  32G Micro SD (TF) card supported
• Storage capacity: 32GB
• LCD: 8.0 inch
• LCD resolution: 1280*800
• Touch screen: capacitive touch screen
• Wi-Fi: supported
• Camera: 5 mega rearview camera
• Working temperature: -10℃～55℃（14℉～131℉）
• Storage temperature: -20℃～70℃（-4℉～158℉）
• Weight: 1kg (Main Unit)
• Dimensions: 254mm*174*mm*35mm
